TB Davies SHERPASCOPIC Aluminium Industrial Telescopic Podium Step

Sherpascopic Podium Steps offer multi-height telescopic adjustment with both front and back sections independently extendable making it ideal for use on staircases or sloping ground.

SKU: #1274-012 Category: Discontinued Tag: Discontinued

Product Description

Sherpascopic Podium Steps offer multi-height telescopic adjustment with both front and back sections independently extendable making it ideal for use on staircases or sloping ground. The large solid platform is surrounded on three sides by 100mm high toe boards and a full height guardrail and is accessed through a folding gate which completely protects the operator from falls. The unit folds easily for transportation in a vehicle or on a roof rack.

Rung to rung telescopic height adjustment
Fully enclosed guardrail provides 360-degree protection
Adjustable for use on staircases and sloping ground
Large anti-slip work platform 600 x 420mm
Fitted with 100mm toe boards
Twin stabilisers to provide maximum stability
Compact and easy to transport and store
Large diameter wheels for ease of movement around site
10-year warranty
Max Load 150kg
EN131-7
PIR 93 353 / PIRL 93 352

SKU	Treads	Platform Height (m)	Approx. Working Height¹ (m)	Closed Height (m)	Width (m)	Open Depth (m)	Weight (kg)
1274-012	3-4	0.8—1.0	2.6—2.8	2.1	0.7	1.4—1.6	23.1^✝
1274-013	5-7	1.1—1.5	2.9—3.3	2.4	0.7	1.6—2.0	26.1^✝
1274-014	8-10	1.8—2.2	3.6—4.0	3.2	0.7	2.2—2.5	31.3^✝
1274-015	8-11	1.8—2.5	3.6—4.3	3.2	0.7	2.2—2.7	33.5^✝

Where applicable, Approx. Working Height¹ is an approximate calculation of 1.75m (5’8″) plus platform height or last climbing tread, whichever is appropriate. Ladders set at an angle of ~75^o degrees.
^✝ Heavy Item – 2-person lift required.
For more information and additional dimension details, please see downloads tab.

For more information about this product range, please download the following PDF(s): Datasheet, Instruction Manual, Brochure Pages

Delivery to UK mainland destinations (England, Wales, Southern Scotland) usually takes between 10 days. For exact times, please call our sales team. Please see the delivery page for more information. Standard deliveries are made between 8AM and 6PM Monday to Friday, except on Bank Holidays.

NB. Image(s) shown are representative of the product. Actual product shipped will depend on size ordered.

Remember to register your warranty within 30 days of the purchase of your TB Davies ladder. Proof of purchase will be required to validate a future claim. Click here to register your warranty today.
